Hollow Body L5 DIY Electric Guitar Kit (PL5-074)

Hi Robert,

Thanks so much for reaching out about our Hollow Body L5 DIY Electric Guitar Kit (PL5-074), and for your question about the wiring diagram! We’re happy to give you all the details you need to make your build as smooth and stress-free as possible.

First, the short and clear answer: Yes! We have a complete, beginner-friendly wiring guide that’s fully compatible with your PL5-074 kit.

We know wiring is often the most intimidating part of a DIY guitar build, so we’ve gone above and beyond to make this as easy as possible for you. Here’s everything you need to know:
1. Your PL5-074 kit uses a super common, industry-standard circuit setup: Dual Humbucker (HH) pickups, 2 Volume and 2 Tone (2V2T) knobs, plus a 3-way pickup selector switch.
2. Instead of the confusing, hard-to-read line schematics you’ll find online, we made a far more user-friendly guide: a full step-by-step wiring walkthrough with real photos of every single connection on a fully assembled set of electronics. You can just follow along and copy each connection, even if you’ve never read a circuit diagram in your life!

The full guide is available right here, and it’s 100% matched to the PL5-074’s circuit setup:
https://www.guitarkit.shop/blogs/wiring-diagram/hh-3w-2v2t-wiring-diagram-cst-930-cst-830-cst-101-cst-730-cst-103-kit

Also, a quick note to make your build even easier: we do all the tricky precision work before your kit even ships! The neck and body are professionally pre-fitted and aligned, with the neck angle perfectly calibrated ahead of time. That means you can pop the neck right onto the body straight out of the box, no complicated sanding or adjusting needed. From there, it’s just adding your custom finish, then installing the hardware and wiring.

If you have any other questions at all, just shoot us a message anytime. We’re here to help with every step of your build!

All the best,
The PANGO Music Team
